Reusable Space Vehicle Ground Operations Baseline Conceptual Model

Modeling efforts for future space operation vehicles at the United States Air Force Research Lab's Air Vehicles Directorate have been focused towards the in flight mission. To better serve the research and development effort, a simulation of the ground operations is required allowing for trade-offs within turnaround operations and between the components that drive those procedures. However, before a simulation can be developed a conceptual model must be generated to guide the model building process. This research provides a baseline conceptual model for reusable space vehicles based on the space shuttle as the only operational vehicle of its kind. The model is built utilizing the Integrated Definition (IDEF) methodology, specifically IDEF3. IDEF3 is focused towards process-viewpoint diagramming and layout.
