Automotive Equipment Usage and Repair Strategies
Diagnostic Strategies of Modern Automotive Systems
By Mandy Concepcion
In this book, we'll cover diagnostic equipment usage. As an automotive activity, diagnosing modern vehicles has become extremely high-tech oriented and difficult. Few professions involve so much from their practitioner. A modern technician has to master a multitude of disciplines, including electronics, optics, mechanics, programming, computer science and many others. Such highly technological activities require a keen analytical mind. But as in any human endeavors, proficiency comes with practice and patience. The techniques presented in this section combined with the necessary hands on practice are designed to sharpen the technician's abilities to perform profitable and fast diagnostics. With patience and practice, any vehicle can be repaired. Enjoy!
Table of Contents
* CURRENT RAMPING STRATEGY - (what's current ramping and how it works, oscilloscope (DSO) and a low/ high amperage clamp-on amp probe, magnetic field, fuel pumps, current ramping a fuel pump, determining the fuel pump speed, commutators, FP waveforms, ignition coil current ramping, Coil-On-Plug current ramping, ignition coil waveforms, current ramping an injector, low Amp probe usage, current ramping compression test)
* HESITATION LACK OF POWER REPAIR STRATEGY - (strategy and operation, fuel delivery test, spark reserve test, exhaust pressure, ignition and valve timing, guidelines for a multi-channel scope, visual inspection, ECM in control, air-fuel ratio, 5-gas analyzer, HC, CO, CO2, O2 and Nox analysis, fuel flow, fuel volume analysis, ignition waveform)
* FUEL FLOW VOLUME GUIDELINES - (Fuel Volume usage for Dometic cars, Fuel Volume usage for Asian cars, Fuel Volume for Continuous injection cars)
* IGNITION COIL WAVEFORM INTERPRETATION - (Parade ignition analysis, Super-imposed, Bar-Graphs, Raster ignition analysis, single cyclnder)
* IGNITION SYSTEM TESTING STRATEGY - (Ignition current waveform interpretation, low resistance or shorted primary ignition, shorted ignition coil, full coil saturation, Ignition testing strategy, ignition waveform interpretation, coil On-Time, Firing line, Dwell, Turn-Off, Spark line, the main 5-types of misfires, triggering device misfire, CRK and CAM, ignition testing procedures, cranking Kilo-Volts, firing line KVs, WOT KVs, Idle baseline, Pre-Loading, Individual spark line, Distributor, DIS and COP)
* A/F RATIO (lean/rich) REPAIR STRATEGY - (Fuel trim diagnostic, air-fuel ratios, ECM in control, Pressure and Volume, Spark issues, O2 not switching)
* MINIMUM AIR RATE ADJUSTMENT - (why do we need a Min. AR adjustment, ECM strategy, IAC strategy, Adjustment procedure, a stalling engine, idle re-learn procedure, battery reset)
* NO FUEL PRESSURE/VOLUME REPAIR STRATEGY - (No pressure volume symptomatic diagnostic, fuel system operation, fuel systems types, returnless fuel system, variable speed fuel pumps, duty-cycle control, steps to diagnose fuel system issues, defective filter, regulator)
* NO INJECTION PULSE STRATEGY - (no injection and pulse diagnostics, crank issues, EFI operation, non-sequential and sequential injection, Direct injection, fuel pulse testing, noid light, injector voltage supply, scanner, the switched side, engine speed signal, injector current)
* NO START/NO SPARK REPAIR PROCEDURE - (Visuals, secondary, ignition grounds, ignition power, primary side, ignition neon noid)
* NO START GENERAL REPAIR PROCEDURE - (procedures that should be used to diagnose a no start, cranks ok condition, spark, pressure, fuel)
